Product Summary
The pm150rra060 is an IPM module. It is suitable for Inverters, UPS, Motion/Servo Control and Power Supplies.
Parametrics
pm150rra060 absolute maximum ratings: (1)Product Category: Drivers; (2)Number of Digits: 20; (3)Number of Segments:160; (4)Package / Case:VSO-56; (5)Maximum Clock Frequency:400 KHz; (6)Operating Supply Voltage:8.50V; (7)Maximum Supply Current:0.12 mA; (8)Maximum Power Dissipation:400 mW; (9)Maximum Operating Temperature:+ 180℃; (10)Minimum Operating Temperature:- 80℃.
Features
pm150rra060 features: (1)Complete Output Power Circuit; (2)Gate Drive Circuit; (3)Protection Logic: Short Circuit, Over Current, Over Temperature, Under Voltage.
![]() |
