Product Summary

The MAX9511CEG is a complete solution to interface a video graphics controller to a VGA port and/or docking station with optimal video performance and minimal electromagnetic interference (EMI) emission. The MAX9511CEG has output drivers with variable EMI suppression for graphics video and sync (RGBHV) signals. The MAX9511CEG includes external load-detection circuitry. The MAX9511CEG operates from 3V and 5V supplies. The DDC circuitry performs bidirectional level translation from 3V to 5V logic levels. The MAX9511CEG is offered in a 24-pin QSOP package and is specified over the commercial 0℃ to +70℃ temperature range. Applications of the MAX9511CEG are: Notebook PCs (Laptops), Docking Stations, Graphics Cards for Notebooks and Personal, Computers, Personal Computer Motherboards with On-Board Video Graphics Controllers, Workstations.

Parametrics

MAX9511CEG absolute maximum ratings: (1)VCC to AGND: -0.3V to +6V; (2)VDD1, VDD2 to DGND: -0.3V to +6V; (3)DGND to AGND: -0.1V to +0.1V; (4)RED_IN, GREEN_IN, BLUE_IN to AGND: -0.3V to (VCC + 0.3V); (5)Operating Temperature Range: 0℃ to +70℃; (6)Storage Temperature Range: -65℃ to +150℃; (7)Lead Temperature (soldering, 10s): 300℃.

Features

MAX9511CEG features: (1)RGB Drivers with Adjustable Slew Rate for EMI Control; (2)H Sync and V Sync Drivers with Level Translation; (3)Bidirectional Level Translators for DDC Support; (4)Simultaneously Drives External Monitor/Projector and Docking Station without Analog RGB Switches—No Stub Reflections; (5)Eliminates Up to 34 External Components; (6)Small 24-Pin QSOP Package.
