Product Summary

The Micron’s MT9P031I12STC is a 1/2.5-inch CMOS digital image sensor with an active-pixel array of 2592H x 1944V. The MT9P031I12STC incorporates sophisticated camera functions such as windowing, binning, column and row skip mode, and snapshot mode.

Parametrics

MT9P031I12STC absolute maximum ratings: (1)Core digital voltage: –0.3 to 1.9 V; (2)I/O digital voltage: –0.3 to 3.1 V; (3)Analog voltage: –0.3 to 3.1 V; (4)Pixel supply voltage: –0.3 to 3.1 V; (5)PLL supply voltage: –0.3 to 3.1 V; (6)Input voltage: –0.3 to VDDQ + 0.3 V; (7)Digital operating current: – 35 mA; (8)I/O digital operating current: – 100 mA; (9)Analog operating current: – 95 mA; (10)Pixel supply current: – 6 mA; (11)PLL supply current: – 6 mA; (12)Operating temperature: –30 to 70 ℃; (13)Storage temperature: –40 to 125 ℃.

Features

MT9P031I12STC features: (1)Micron DigitalClarity imaging technology; (2)High frame rate; (3)Superior low-light performance; (4)Low dark current; (5)Global reset release, which starts the exposure of all rows simultaneously; (6)Bulb exposure mode, for arbitrary exposure times; (7)Snapshot mode to take frames on demand; (8)Horizontal and vertical mirror image.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MT9P031I12STC
MT9P031I12STC


SENSOR IMAGE COLOR CMOS 48-LCC

Data Sheet

0-1: $10.90
1-25: $9.27
25-100: $8.58
100-250: $7.90
250-500: $7.57
MT9P031I12STC PROT FILM
MT9P031I12STC PROT FILM


SNSR IMAGE DGTL COLOR 48-LCC

Data Sheet

0-240: $11.15
MT9P031I12STCD ES
MT9P031I12STCD ES


KIT DEV FOR MT9P031

Data Sheet

0-1: $716.04
MT9P031I12STCH ES
MT9P031I12STCH ES


KIT HEAD BOARD FOR MT9P031

Data Sheet

0-1: $206.55
