PIC18F45K22-IPT

Low-Power, High-Performance Microcontroller, QFP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.16~2.47 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.16~2.47

PartNumber:: PIC18F45K22-IPT

Brand:: Microchip Technology - Microchip | Pack: QFP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. sam's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-05-16

From Other Seller

Part Number:PIC18F45K22-IPT
US $2.16 - 2.47
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PIC18F45K22-IPT is a Low-Power, High-Performance Microcontroller with nanoWatt XLP Technology.

Parametrics

Absolute maximum ratings: (1)Ambient temperature under bias:-40℃ to +125℃; (2)Storage temperature:-65℃ to +150℃; (3)Voltage on any pin with respect to VSS (except VDD, and MCLR):-0.3V to (VDD + 0.3V); (4)Voltage on MCLR with respect to VSS:0V to +11.0V; (5)Total power dissipation:1.0W; (6)Maximum current out of VSS pin (-40℃ to +85℃):300 mA; (7)Maximum current out of VSS pin (+85℃ to +125℃):125 mA; (8)Maximum current into VDD pin (-40℃ to +85℃):200 mA ; (9)Maximum current into VDD pin (+85℃ to +125℃):85 mA; (10)Input clamp current, IIK (VI < 0 or VI > VDD):±20 mA; (11)Output clamp current, IOK (VO < 0 or VO > VDD):±20 mA; (12)Maximum output current sunk by any I/O:25 mA; (13)Maximum output current sourced by any I/O pin:25 mA; (14)Maximum current sunk by?all ports (-40℃ to +85℃):200 mA; (15)Maximum current sunk by?all ports (+85℃ to +125℃):110 mA; (16)Maximum current sourced by all ports (-40℃ to +85℃):185 mA; (17)Maximum current sourced by all ports (+85℃ to +125℃):70 mA.

Features

Features: (1)Up to 1024 Bytes Data EEPROM; (2)Up to 64 Kbytes Linear Program Memory Addressing ; (3)Up to 3896 Bytes Linear Data Memory Addressing; (4)Up to 16 MIPS Operation; (5)16-bit Wide Instructions, 8-bit Wide Data Path; (6)Priority Levels for Interrupts ; (7)31-Level, Software Accessible Hardware Stack; (8)8 x 8 Single-Cycle Hardware Multiplier; (9)Four Crystal modes up to 64 MHz; (10)Two External Clock modes up to 64 MHz; (11)4X Phase Lock Loop (PLL); (12)Secondary Oscillator using Timer1 @ 32 kHz; (13)Sleep mode: 20 nA, typical; (14)Watchdog Timer: 300 nA, typical; (15)Timer1 Oscillator: 800 nA @ 32 kHz; (16)Peripheral Module Disable.
